Naked MINI Freshwater System
  • Naked MINI Freshwater System
Naked MINI Freshwater System

Naked MINI Freshwater System

Compact freshwater pool sanitisation for pools and swim spas up to 30,000 litres, combining oxidation and copper-silver ionisation for clear water with very low chlorine and salt levels.
Professional installation included
Manufacturer warranty
Local Perth metro support
Model
Quick Price Check

Want to chat? Call or text 0466 029 049 and we’ll help you choose the right option for your pool.

Freshwater swimming Maintains clear water with very low chlorine and salt levels
Hybrid sanitisation Combines oxidation with copper-silver ionisation to control bacteria and algae
Made for smaller pools Compact system designed specifically for plunge pools, swim spas and pools up to 30,000 litres
Smart system control Digital control includes boost modes, timers, winter mode and pump protection

Enjoy the benefits of a Naked Freshwater Pool in a compact system designed specifically for smaller pools, plunge pools and swim spas up to 30,000 litres.

The Naked MINI (NKD-M) uses the same combination of copper/silver ionisation and oxidation technology as the larger Naked Freshwater System, helping deliver clean, clear and soft-feeling water with reduced reliance on traditional pool chemicals.

Its compact design makes it ideal where equipment space is limited, without sacrificing the freshwater experience Naked is known for.

Key Benefits

  • Designed for pools and swim spas up to 30,000 litres

  • Compact design for smaller equipment areas

  • Copper/silver ionisation + oxidation

  • Soft, fresh-feeling water

  • Reduced reliance on traditional pool chemicals

  • Low-maintenance operation

  • Suitable for smaller pools, plunge pools and swim spas

  • Compatible with the optional Naked pH Controller for automatic pH management

Warranty

The Naked MINI currently carries a 3-year warranty on the digital control unit and oxidiser electrode, with the oxidiser electrode also limited to 10,000 operating hours. Ioniser rods are consumable items and are not covered by warranty.

Contact Splash Point – Pool Solutions for product selection, pool suitability, supply and professional installation.

Specifications

Model: NKD-M
Application: Small pools, plunge pools and swim spas
Maximum pool volume: 30,000 litres

Sanitisation method:
Oxidation and copper-silver ionisation

Input voltage: 220–265V AC
Input current: 0.4A
Total power consumption: 93W
Frequency: 50/60Hz

Oxidiser output:
10.3V DC
5A DC
10g/hr chlorine equivalent at 800ppm TDS

Pump outlet rating: 9.4A

Water connection: 40/50mm
Recommended water flow: 80–550 L/min
IP rating: IP23

Control unit dimensions:
204W x 286H x 105D mm

Oxidiser cell housing:
356L x 145D x 203H mm

Ioniser housing:
158L x 100D x 138H mm

Net weight: 9.5kg

Recommended water chemistry:
Free chlorine: 0–0.5ppm
Total chlorine: 0–0.5ppm
pH: 7.2–7.6
Total alkalinity: 80–150ppm
Calcium hardness: 80–250ppm
Copper: 0.2–0.7ppm
Salt / mineral salt: 500–700ppm
TDS: 800–1,200ppm
Phosphates: 0–0.2ppm

Installation

The Naked MINI Freshwater System should be professionally installed and commissioned to suit the pool volume, filtration system and water conditions.

Installation includes plumbing the oxidiser and ioniser housings into the pool filtration return line, mounting and connecting the digital control unit and programming the system for the correct pool volume and filtration schedule.

The system requires 40/50mm plumbing connections and sufficient water flow through the oxidiser cell.

The pool water must be correctly balanced and brought to the required freshwater salt or mineral concentration before commissioning.

The control unit must be protected from the elements and installed in a well-ventilated position.

The NKD-M is also compatible with the optional Naked pH Controller and heater interlock.

Splash Point – Pool Solutions can supply, install, configure and commission the Naked MINI Freshwater System.

Warranty

Naked Pools provides the following Australian warranty for the NKD-M Freshwater System:

Digital control unit: 3 years

Oxidiser electrode: 3 years or 10,000 operating hours, whichever occurs first

Ioniser rods: Consumable item and not covered by warranty

Commercial installation: 12 months unless a commercial model is purchased

Commercial models: 24 months

The warranty is back-to-base and is subject to correct installation, ventilation, water balance, maintenance and operating conditions.

Australian Consumer Law rights apply in addition to the manufacturer warranty.
